TrueNAS CORE + Supermicro CSE-721TQ-350B2
Compact Mini-Tower: D 11"x W 8.27"x H 9.45" Support wide range of Mini-ITX (6.75"x 6.75") motherboards 4 3.5" Hot-Swap SATA3/SAS2 drive bays, 2 internal 2.5" SATA drive bays, and 1 slim DVD-ROM drive bay 2 USB3.1 Gen1 ports(front), chassis intrusion switch, Kensington Lock supported
| Kód produktu | 302.171975 |
|---|---|
| Part number | TRUEC-721TQ-350B2 |
| Výrobca | ANAFRA |
| Dostupnosť | Na požiadavku |
| Záruka | 36 mesiacov |
| Hmotnosť | 6.8 kg |
| Uvedená cena je vrátane všetkých zákonných poplatkov | |
Podrobné informácie
- World’s Most Popular Storage OS
- Unified Storage Built on OpenZFS
- Installs on Hardware or VMs
- Community-Supported
Share Files. Serve Media. Store Anything.
TrueNAS CORE can be used from the home to the office to the data center for a variety of data-intensive use cases. IT professionals, photographers, designers, audio/video producers and editors, developers, and any user serious about storing and protecting lots of data can take advantage of TrueNAS CORE. Pair it with your favorite backup software to archive large quantities of infrequently used data off of your local devices and even sync and push data to the cloud.
Nothing Protects Your Data Like ZFS
At the heart of TrueNAS is the self-healing OpenZFS filesystem. Previously only available on the highest-end enterprise storage systems, TrueNAS gives you direct, user-friendly access to ZFS. With its built-in RAID, powerful data management tools, and ability to automatically detect and repair silent data corruption (and bit rot), TrueNAS and OpenZFS ensure data integrity from start to finish.
Go Beyond “NAS”
More than a traditional “Network Attached Storage”, TrueNAS is Unified Storage that integrates seamlessly into any environment with a variety of file, block, or object access protocols. You can also expand its functionality with a variety of free plugins, like Plex Media Server, NextCloud, Zoneminder surveillance, and many others.
-
- Motherboard
Part number MBD-X12STL-IF-B - Processor
CPU Intel Xeon RKL-E E-2324G Socket LGA 1200 TDP 65 W - System memory
Memory maximum Capacity 64 GB Memory Slots 2 Memory Type DDR4 Error Detection (ECC) Yes Installed memory
Samsung 32GB 3200MHz DDR4 ECC UDIMM 2R×8 - M391A4G43BB1-CWE- Input/output
Network 2 RJ45 Gigabit Ethernet LAN ports USB 4 USB 2.0 port(s) (2 via header; 2 rear)
4 USB 3.2 Gen1 port(s) (2 via header; 2 rear)Video 1 VGA
-
- Expansion slots
PCIe 1 PCIe 4.0 x16 - Dimensions
Form Factor Mini-Tower Height 240.03 mm Width 210.06 mm Depth 279.4 mm Weight 6.8 kg - Storage
Drive Bays 2x 2.5" fixed drive bay
4x 3.5" hot-swap SAS/SATA drive bayM.2 M.2 Interface: 1 PCIe 3.0 x4
Form Factor: 2280
Key: M-KeyInstalled Storage Samsung PM9A1 M.2 (2280) 256GB (PCIe 4.0/NVMe) - MZVL2256HCHQ-00B00 - Power supply
Certification Gold Power 350 W QTY 1
- Optional parts
| Name | Part Number | ||
|---|---|---|---|
| Components | SSD, RAM | if wanted, write request to note for additional installation of components |
Parametre
| Veľkosť U | Mini-Tower |
|---|---|
| Výrobca CPU | Intel |
| Počet jadier | 4 |
| Frekvencia CPU (GHz) | 3,1 |
| Maximálný počet slovov DIMM pre pamäť | 2 |
| Počet pevných diskov | 1 |
| Výkon (W) | 350 |
| Certifikácia účinnosti | Gold |
